SKU |
EN3DC40+ |
Output Voltage |
12V Nominal (8.0V min) |
Output Current (Maximum) |
40A ~ 50A |
Output Power |
775W |
Selectable Battery Type |
Gel, AGM, Flooded, Lithium, Program |
Charger Voltage Range |
13.8V – 15.5V |
Float Voltage Range |
13.0V – 13.8V |
Charger Current (User Selectable) |
5/10/15/20/25/30/35/40/45/50A (default 40A) |
Equalize Voltage (Flooded Battery) |
15.5V |
Equalize Charging Current |
10% of Bulk Current Setting |
Charging Control |
2 stage / 3 stage selectable (Default 3 stage) |
DC Output Bank |
Single |
Current Draw from CH1 when not in use |
< 50mA |
Battery Temperature Setting |
Low/ Normal/ High (Battery Temperature Sensor Standard) |
Efficiency |
95% |
Input Voltage |
14.5 – 45VOC |
Maximum Input |
≤ 23V input, 500W (600W allowable), ≥37.5V-45V input, 750W (800W allowable) |
Input Voltage |
10.5 – 16VDC / 21 – 32VDC |
Height x Width x Depth |
242mm x 172mm x 74mm |
Unit Weight |
1.85 Kg |
Shipping Weight |
2.17 kg |
Warranty |
5 Years |
