REDARC BCDC Alpha25 25A DC-DC battery charger with solar input for caravan and 4WD

REDARC BCDC Alpha25 Battery Charger RedArc

REDARC BCDC Alpha25 Battery Charger

SKU BCDC12025B

$799.00

Recommended Battery Capacity: 40–300 Ah
Weight: 925 g
Dimensions: 164 × 146 × 44 mm
Operating Temperature: -40°C to 85°C

All specifications

or pay now with

Questions? for expert advice, or read our buying guides

Key features

25A charging output from both DC (alternator) and solar power sources, usable simultaneously
Green Power Priority™ prioritises solar input to minimise alternator load and save fuel
Compatible with all common automotive battery types: AGM, gel, calcium, standard lead-acid, and lithium (LiFePO4) including heated lithium
IP67 and IP69K dual-rated protection against dust ingress and high-pressure water jets
Adjustable input current limit safeguards modern variable-voltage and Euro 6 alternators
Push-button start-battery recovery mode can recover a flat cranking battery in as little as 15 minutes
Remote monitoring and control via the RedVision app over Bluetooth
Over-the-air (OTA) firmware updates keep the unit current with new battery technologies and features
Accepts up to 500W solar array input (9–48V DC) for off-grid and stationary charging
Charge back to the start battery with excess solar power when the auxiliary battery is full
Screw terminals and push-button interface for simple installation with no soldering
Temperature compensation for accurate charging across Australian climate extremes from -40°C to 85°C

Overview

The REDARC BCDC Alpha25 is a rugged 12V 25A DC-DC battery charger that keeps your caravan, camper trailer or 4WD auxiliary battery topped up from both the vehicle's alternator and solar at the same time. Its Green Power Priority™ prioritises solar input to reduce load on your alternator and save fuel, while the IP67/IP69K rating shields it against dust, mud and high-pressure water. Designed, tested and manufactured in Australia, it charges AGM, gel, calcium, lead-acid and standard or heated LiFePO4 lithium batteries.

Built for Australian conditions, the BCDC Alpha25 suits engine-bay installation in tow vehicles, 4WD tourers, motorhomes and RVs that spend weeks off-grid on corrugated tracks and in dusty outback camps. A push-button start-battery recovery mode can bring a flat cranking battery back to life in as little as 15 minutes, and excess solar can top up the start battery once your house battery is full. Screw terminals and a push-button interface make installation straightforward for your auto electrician, and the RedVision app gives you Bluetooth monitoring from the camp chair.

Key Features

25A DC-DC charging from alternator and solar, used simultaneously with Green Power Priority
Charges AGM, gel, calcium, lead-acid and standard or heated LiFePO4 lithium batteries
IP67/IP69K dust and water protection, designed and manufactured in Australia
Start battery recovery at the push of a button, in as little as 15 minutes
Bluetooth monitoring and control via the RedVision app, with over-the-air updates

Download file

Delivery, returns & warranty

Shipping & Returns

Shipping

Outdoor Camping Australia operates a nationwide distribution network, with items shipping from:

Our warehouse in Bendigo, Victoria
Partner supplier warehouses on the East Coast
Partner supplier warehouses on the West Coast

This multi-location approach allows us to provide efficient delivery across Australia. Use our shipping calculator on the product pages for accurate delivery times and costs to your location.

Important Shipping Notes:

We cannot deliver to PO Boxes, Private Mail Bags or Parcel Lockers
Depot pickup options may be available at reduced rates (contact us to discuss)
Off-mainland deliveries require additional shipping fees (custom quoted)
Missed deliveries may incur a redelivery fee set by the courier
All shipments managed through our trusted delivery partners including Border Express, VicTas, DHL, StarTrack, AusPost, Sendle and Aramex

Returns

As outlined in our Refund Policy, we follow the Australian Consumer Law (ACL) which protects consumers by providing certain guaranteed rights when buying goods and services.

You can return items if:

The product is faulty or not of merchantable quality
The product is not fit for its intended purpose
The product does not match the description
You can present proof of purchase

For change of mind returns:

Item must be in original condition with tags attached
Must be returned within 30 days of purchase
Original proof of purchase required
Return shipping is at customer's expense
Original delivery charges are non-refundable unless due to our error

Refunds will be processed within 10 business days of receiving and inspecting the return.

For full details, please refer to our:

Warranty Details

+

REDARC provides a 2-year manufacturer warranty against defects in materials and workmanship.

Specifications

Dimensions	164 × 146 × 44 mm (6.46" × 5.75" × 1.73")
Weight	925 g (32.6 oz)
IP Rating	IP67 / IP69K
Operating Temperature	-40°C to 85°C (-40°F to 185°F)
Nominal Charge Current	25A
DC Input (Start Battery)	9–32V DC, maximum current 28A
Solar Input	9–48V DC, maximum current 28A, maximum array 500W
Output Voltage & Current	12V nominal (9–16V DC range), maximum 25A / 400W
Recommended Battery Capacity	40–300 Ah
AGM / Gel Charging Voltages	Boost 14.5V (AGM) / — (Gel), Float 13.3V
Calcium Charging Voltages	Boost 15.2V, Float 13.3V
Standard Lead-Acid Charging Voltages	Boost 14.9V, Float 13.3V
Lithium (LiFePO4) Charging Voltages	Boost 14.2V, Float 13.6V (standard & heated)
Battery Temperature Range	AGM/Calcium/SLA: -25°C to 90°C \| Gel: 0°C to 90°C \| LiFePO4 standard: 0°C to 60°C \| LiFePO4 heated: -25°C to 60°C
Temperature Compensation	AGM/Calcium/Gel/SLA: -30 mV/°C (0–60°C) \| LiFePO4: -70 mV/°C (40–60°C)
