| SKU |
BCDCN1225 |
| Brand |
REDARC |
| Unit Of Measure |
ea |
| Installation Location |
In Vehicle Only (In-Cabin) |
| Connector Type |
Bare wire |
| Compatible Battery Types |
Standard Lead Acid, Calcium, Gel, AGM or LiFePO4 |
| Power Type |
DC to DC |
| Charging Stages |
Three-stage (Boost, Absorption, Float) |
| Continuous Current Rating |
25A |
| Maximum Current Rating |
35A |
| Input Voltage Range |
9 - 32V |
| Solar Input Voltage |
9 - 32V (unregulated only) |
| Solar Switch on Voltage |
9V |
| Output Voltage |
12 VDC |
| Maximum Charging Voltage |
15.3V |
| Nominal Output Power |
375W |
| No Load Current |
<100mA |
| Standby Current |
<8mA |
| Operating Temperature |
-15°C to 80°C |
| Profile A Maximum Voltage |
14.6V (AGM/Gel) |
| Profile B Maximum Voltage |
15.0V (Standard Lead Acid) |
| Profile C Maximum Voltage |
15.3V (Calcium) |
| Profile Li Maximum Voltage |
14.5V (LiFePO4) |
| Input Fuse Rating (not supplied) |
40A |
| Output Fuse Rating (not supplied) |
40A |
| Minimum Output Battery Voltage |
0.1V |
| Weight |
0.9 kg |
| Dimensions |
165 x 120 x 37 mm (L x W x D) |
| Shipping Weight |
1.0000 kg |
| Shipping Dimensions |
Length => 0.330 m, Width => 0.130 m, Height => 0.060 m |
| Shipping Volume |
0.002574000 m³ |
| Warranty Period |
2 Years |
| Standards |
CISPR11, ECE Reg.10 |
