The KT Solar 20Amp + 20Amp Dual Battery Charging PWM Solar Controller is a safe and efficient solution for regulating solar power for monocrystalline solar panels ranging from 100W to 240W. This controller allows you to charge and maintain two batteries simultaneously, making it perfect for 12V and 24V solar charging systems. It is compatible with a wide variety of battery types, ensuring versatile use for all your solar power needs.
Key Features
-
6 Charging Stages: Trickle, Boost, Absorb, Float Full, and Maintain Float stages are indicated on the LCD display for easy real-time tracking.
-
LCD Display: Provides real-time cycling through solar source VOC, charging input voltage, total charging current, battery voltage, battery charging current, and charging AH.
-
Battery Temperature Display: Displays battery temperature during intervals for additional monitoring.
-
User-Friendly Interface: Easy settings selection via soft-touch buttons.
-
VOC Tracking: Real-time VOC tracking to optimize solar harvest.
-
Battery Compatibility: Compatible with GEL, WET, AGM, Calcium, LTO, LiFePO4, and Li-Ion batteries, with AGM as the default setting.
-
Safety Protections: Features six safety protections, including overcharge, reverse polarity, short circuit, working battery temperature, reverse charging, and internal over-temperature protection.
-
Included Accessories: Comes with 2 x 5m temperature probe leads.
Specifications
-
Model Number: KT70784
-
Charging Current: 20Amp + 20Amp
-
Suitable Solar Panel Range: 100W to 240W
-
Compatible Battery Types: GEL, WET, AGM, Calcium, LTO, LiFePO4, Li-Ion
-
Safety Features: Overcharge, Reverse Polarity, Short Circuit, Working Battery Temperature, Reverse Charging, Internal Over Temperature protection
-
Included Accessories: 2 x 5m Temperature Probe Leads
The KT Solar 20Amp + 20Amp Dual Battery Charging PWM Solar Controller (Model No. KT70784) is designed to provide a safe and efficient method of regulating solar power for monocrystalline solar panels from 100W up to 240W. This controller is capable of charging and maintaining two batteries simultaneously, making it suitable for both 12V and 24V solar charging systems. The controller features an LCD display that provides real-time tracking of various parameters, including solar source VOC, charging input voltage, total charging current, battery voltage, battery charging current, and charging AH. Additionally, the battery temperature is displayed during intervals for further monitoring. The user-friendly interface with soft-touch buttons allows for easy settings selection, while real-time VOC tracking optimizes solar harvest. Compatible with a range of battery types, including GEL, WET, AGM, Calcium, LTO, LiFePO4, and Li-Ion, this controller offers versatility and reliability. It also includes six safety protection features to ensure safe operation. The package comes with two 5m temperature probe leads for added convenience.
