Key features
- Advanced MPPT tracking algorithm provides up to 30% more energy harvest than PWM solar charge controllers
- Auto-detects 12V or 24V nominal system voltage for plug-and-play installation
- Supports sealed, gel, flooded, and user-defined lead-acid batteries plus LiFePO4 and Li-NiCoMn lithium chemistries
- RS485 interface with standard MODBUS protocol enables connectivity to MT50 remote meter, Wi-Fi module, Bluetooth adapter, and IoT cloud platform
- Rated 10A charge and discharge current; handles solar arrays up to 130W at 12V or 260W at 24V
- Maximum PV open-circuit voltage of 60V (at minimum operating temperature) — safe for series-connected panels
- Fully programmable charge voltage parameters for each battery type, including user-defined profiles
- Built-in 5V/150mA auxiliary power output for powering communication accessories
- Comprehensive protection suite: overcharge, over-discharge, short-circuit, reverse polarity, overtemperature, and PV reverse current
- Certified to EN, EMC, and RoHS standards — suitable for use in caravans, RVs, camper trailers, and off-grid systems
Overview
The EPever Tracer 1206BP is a 10A IoT-ready MPPT (Maximum Power Point Tracking) solar charge controller that delivers up to 30% greater charging efficiency than conventional PWM controllers — meaning your solar panels work harder, your batteries charge faster, and you get more usable power every day. Operating on 12V or 24V auto-detect systems and accepting a maximum PV open-circuit voltage of 60V, it handles solar arrays up to 130W at 12V or 260W at 24V. Its built-in RS485 interface with MODBUS protocol connects seamlessly to the MT50 remote meter, Wi-Fi module, Bluetooth adapter, or EPever's IoT cloud platform for real-time system monitoring and control from anywhere.
Purpose-built for Australian caravan, RV, camper trailer, and off-grid setups, the Tracer 1206BP supports sealed, gel, flooded, and user-defined lead-acid batteries as well as LiFePO4 and Li-NiCoMn lithium chemistries — covering virtually every battery type you'll find in a modern 4WD touring or motorhome build. Fully programmable charge parameters and automatic low-voltage disconnect protect your battery bank on remote trips, while the comprehensive protection suite — overcharge, over-discharge, short-circuit, reverse polarity, and overtemperature — keeps your system safe in the harshest Australian outback conditions. Certified to EN, EMC, and RoHS standards, this compact controller is a reliable foundation for any serious off-road or off-grid power system.
Key Features
- Advanced MPPT tracking algorithm delivers up to 30% more energy harvest than PWM controllers
- Auto-detects 12V or 24V system voltage — no manual configuration required
- RS485/MODBUS interface compatible with MT50 remote meter, Wi-Fi, Bluetooth, and IoT cloud monitoring
- Supports lead-acid (sealed, gel, flooded) and lithium (LiFePO4, Li-NiCoMn) battery chemistries
- Comprehensive protection: overcharge, over-discharge, short-circuit, reverse polarity, and overtemperature
Delivery, returns & warranty
Shipping & Returns
Shipping
Outdoor Camping Australia operates a nationwide distribution network, with items shipping from:
- Our warehouse in Bendigo, Victoria
- Partner supplier warehouses on the East Coast
- Partner supplier warehouses on the West Coast
This multi-location approach allows us to provide efficient delivery across Australia. Use our shipping calculator on the product pages for accurate delivery times and costs to your location.
Important Shipping Notes:
- We cannot deliver to PO Boxes, Private Mail Bags or Parcel Lockers
- Depot pickup options may be available at reduced rates (contact us to discuss)
- Off-mainland deliveries require additional shipping fees (custom quoted)
- Missed deliveries may incur a redelivery fee set by the courier
- All shipments managed through our trusted delivery partners including Border Express, VicTas, DHL, StarTrack, AusPost, Sendle and Aramex
Returns
As outlined in our Refund Policy, we follow the Australian Consumer Law (ACL) which protects consumers by providing certain guaranteed rights when buying goods and services.
You can return items if:
- The product is faulty or not of merchantable quality
- The product is not fit for its intended purpose
- The product does not match the description
- You can present proof of purchase
For change of mind returns:
- Item must be in original condition with tags attached
- Must be returned within 30 days of purchase
- Original proof of purchase required
- Return shipping is at customer's expense
- Original delivery charges are non-refundable unless due to our error
Refunds will be processed within 10 business days of receiving and inspecting the return.
For full details, please refer to our:
Warranty Details
+
Warranty Details
+
- 12-month manufacturer warranty against defects in materials and workmanship.
Specifications
| Model | Tracer 1206BP (EPS-2606BP10A) |
|---|---|
| Nominal System Voltage | 12/24VDC Auto-detect |
| Rated Charge Current | 10A |
| Rated Discharge Current | 10A |
| Max PV Input Power | 130W (12V) / 260W (24V) |
| Max PV Open Circuit Voltage | 60V (at minimum operating temp); 46V (at 25°C) |
| MPP Voltage Range | (Battery voltage + 2V) to 36V |
| Battery Input Voltage Range | 8.5–32VDC |
| Self-Consumption | ≤13mA at 12V; ≤11.5mA at 24V |
| Battery Types Supported | Sealed, Gel, Flooded, User-defined (lead-acid); LiFePO4, Li-NiCoMn, User-defined (lithium) |
| Equalize Charge Voltage (Lead-Acid) | Sealed: 14.6V; Gel: disabled; Flooded: 14.8V; User-defined: 9–17V (×2 for 24V) |
| Boost Charge Voltage (Lead-Acid) | Sealed: 14.4V; Gel: 14.2V; Flooded: 14.6V; User-defined: 9–17V (×2 for 24V) |
| Float Charge Voltage (Lead-Acid) | Sealed/Gel/Flooded: 13.8V; User-defined: 9–17V (×2 for 24V) |
| Low Voltage Disconnect | Sealed/Gel/Flooded: 11.1V; User-defined: 9–17V (×2 for 24V) |
| Low Voltage Reconnect | Sealed/Gel/Flooded: 12.6V; User-defined: 9–17V (×2 for 24V) |
| Boost Charge Voltage (Lithium) | LiFePO4: 14.5V; Li-NiCoMn: 12.5V; User-defined: 9–17V (×2 for 24V) |
| Temperature Compensation | -3mV/°C/2V |
| Communication Interface | RS485 (MODBUS protocol) |
| Auxiliary Power Output | 5V / 150mA |
| Certifications | EN, EMC, RoHS |
-
