Victron Cerbo GX Mk2 System Controller Victron

Victron Cerbo GX Mk2 System Controller

SKU BPP900451100

$419.00

Weight: Approx. 0.3 kg
Dimensions (L×W×H): 130 × 80 × 35 mm
Temperature Sensor Inputs: 2× resistive temperature sensor inputs

All specifications

or pay now with

Questions? for expert advice, or read our buying guides

Key features

Dual-core processor delivers fast, responsive system management across all connected devices
Venus OS v3.0 with refreshed human-centred UI and updated colour scheme for easier at-a-glance monitoring
Built-in Wi-Fi Access Point and client mode plus Bluetooth for wireless device connection and app control
Ethernet LAN port for wired network integration and VRM portal connectivity
Two VE.Direct ports and one VE.Bus port for direct connection to Victron MPPT controllers and inverter/chargers
CAN-bus port enables deep integration with managed lithium batteries (BMS) from leading third-party manufacturers
Three resistive tank level inputs for fresh water, grey water, and fuel monitoring
Two temperature sensor inputs for battery and ambient temperature tracking
Two programmable relay outputs support auto start/stop generator control
Micro SD card slot for offline data logging when remote connectivity is unavailable
HDMI output and two USB ports for connecting optional display devices
Four digital inputs for door alarms, bilge pumps, or other ancillary monitoring triggers
Compatible with optional GX Touch 50 and GX Touch 70 waterproof touchscreen displays
Integrates with Marine MFDs via NMEA 2000 / MFD App integration
DIN-rail mountable with compact form factor for easy installation in any caravan, RV, or off-grid cabinet

Overview

The Victron Cerbo GX Mk2 is the nerve centre of any serious 12V power system — a next-generation communication hub built on a powerful dual-core processor and running the latest Venus OS v3.0 for intuitive, real-time monitoring of every component in your setup. With built-in Wi-Fi (Access Point and client mode), Bluetooth, Ethernet, two VE.Direct ports, a VE.Bus port, and a CAN-bus port, the Cerbo GX Mk2 connects seamlessly to Victron inverter/chargers, MPPT solar charge controllers, lithium battery management systems, and an ever-growing library of third-party devices — giving you a single unified view of your entire electrical system, locally or from anywhere in the world via the free Victron Remote Management (VRM) portal.

Purpose-built for Australian caravanners, RV travellers, 4WD tourers, and off-grid home setups, the Cerbo GX Mk2 thrives where reliable power management matters most — whether you're parked up at a remote outback campsite, running solar and lithium batteries through your caravan, or managing shore power alongside a generator on a long-haul trip. Connect an optional GX Touch 50 or GX Touch 70 waterproof touchscreen for on-the-wall control, pair it with your Marine MFD via NMEA 2000, or use the VictronConnect app on your smartphone. Three resistive tank level inputs, two temperature sensor ports, a Micro SD card slot for offline data logging, and two programmable relay outputs for auto start/stop generator control make this the definitive system controller for any serious off-road or off-grid power setup in Australia.

Key Features

Dual-core processor running Venus OS v3.0 for fast, intuitive system monitoring
Built-in Wi-Fi (AP + client), Bluetooth, Ethernet, VE.Direct ×2, VE.Bus, and CAN-bus connectivity
Monitors and controls the full Victron ecosystem plus a wide range of third-party devices
Free Victron Remote Management (VRM) portal for anywhere-in-the-world system access
Compatible with optional GX Touch 50/70 touchscreen, Marine MFDs via NMEA 2000, and VictronConnect app

Delivery, returns & warranty

Shipping & Returns

Shipping

Outdoor Camping Australia operates a nationwide distribution network, with items shipping from:

Our warehouse in Bendigo, Victoria
Partner supplier warehouses on the East Coast
Partner supplier warehouses on the West Coast

This multi-location approach allows us to provide efficient delivery across Australia. Use our shipping calculator on the product pages for accurate delivery times and costs to your location.

Important Shipping Notes:

We cannot deliver to PO Boxes, Private Mail Bags or Parcel Lockers
Depot pickup options may be available at reduced rates (contact us to discuss)
Off-mainland deliveries require additional shipping fees (custom quoted)
Missed deliveries may incur a redelivery fee set by the courier
All shipments managed through our trusted delivery partners including Border Express, VicTas, DHL, StarTrack, AusPost, Sendle and Aramex

Returns

As outlined in our Refund Policy, we follow the Australian Consumer Law (ACL) which protects consumers by providing certain guaranteed rights when buying goods and services.

You can return items if:

The product is faulty or not of merchantable quality
The product is not fit for its intended purpose
The product does not match the description
You can present proof of purchase

For change of mind returns:

Item must be in original condition with tags attached
Must be returned within 30 days of purchase
Original proof of purchase required
Return shipping is at customer's expense
Original delivery charges are non-refundable unless due to our error

Refunds will be processed within 10 business days of receiving and inspecting the return.

For full details, please refer to our:

Warranty Details

+

Warranty & Returns

Limited 12 Month Manufacturer Warranty

If you experience issues with your gear, please contact us for support.

What’s Covered?

Manufacturing defects
Faults in materials or workmanship

What’s Not Covered?

Damage caused by misuse, neglect, or improper use
Incidents occurring during delivery
Normal wear and tear from usage

How to Initiate a Warranty Claim

If you need to file a warranty claim, please follow these steps:

Contact us via email or the via the contact us
Provide the following details:
- Order ID
- Detailed description of the issue
- Images/videos clearly showcasing the fault (ensure they meet the recommended format and size for optimal review)
Our team will assess your claim and get back to you as soon as possible.

Note: Do not open a PayPal dispute, as this may delay the resolution process. Please follow the official claim process for quicker results.

⚠ Important Note:
We recommend testing your purchased product within one year of purchase. We cannot help process warranty claims beyond this period.

For full details, please refer to our other policies:

Specifications

SKU / Part Number	BPP900451100
Generation	Mk2 (second generation)
Processor	Dual-core ARM Cortex-A7
Operating System	Venus OS v3.0
Input Voltage Range	8–70 V DC
Power Consumption	Approx. 1 W
Wi-Fi	2.4 GHz 802.11 b/g/n — Access Point and Client mode
Bluetooth	Bluetooth 4.0 LE
Ethernet	1× RJ45 10/100 Mbps LAN
VE.Direct Ports	2× VE.Direct (serial)
VE.Bus Port	1× RJ45 VE.Bus (for Multi/Quattro inverter-chargers)
CAN-bus Port	1× CAN-bus (supports NMEA 2000 and managed lithium batteries)
USB Ports	2× USB-A
HDMI Output	1× HDMI (for GX Touch or external display)
Digital Inputs	4× digital inputs (configurable alarms / pulse meter)
Relay Outputs	2× programmable relay (30 V DC / 3 A)
Temperature Sensor Inputs	2× resistive temperature sensor inputs
Tank Level Inputs	3× resistive tank level inputs (0–180 Ω or 180–0 Ω)
Storage	Micro SD card slot (up to 32 GB)
Dimensions (L×W×H)	130 × 80 × 35 mm
Weight	Approx. 0.3 kg
Operating Temperature	-20 °C to +50 °C
Certifications	CE, RCM
Country of Origin	Netherlands
