Key features
- Rated voltage: 500V DC, suitable for 12V to 48V solar and battery systems
- 2-pole (double-pole) configuration simultaneously disconnects both poles of the DC circuit
- 25A continuous current rating with 6kA rated breaking capacity (Icu/Ics)
- Thermal-magnetic trip mechanism offers dual protection: overload (thermal) and short-circuit (magnetic)
- DIN-rail mount (35mm standard) for quick and secure installation in enclosures and distribution boards
- Compact, space-saving form factor ideal for caravans, motorhomes, camper trailers, and 4WD canopies
- Manual ON/OFF toggle for controlled isolation during maintenance, servicing, or system shutdown
- IEC 60947-2 / DC MCB standard construction with UL and CE compliance
- Durable, flame-retardant thermoplastic housing rated for outdoor-adjacent and vibration-prone environments
- Suitable for solar PV combiner boxes, battery disconnect applications, and DC load protection
Overview
The Slocable MCB 500V 2P 25A DC Solar Isolator is a heavy-duty 2-pole miniature circuit breaker engineered specifically for direct-current solar PV systems operating at up to 500V DC. Rated at 25A continuous current with a 6kA breaking capacity and a thermal-magnetic trip mechanism, it delivers robust dual-mode protection — overload protection via thermal response and instantaneous short-circuit protection via magnetic trip — keeping your solar array, battery banks, and DC distribution circuits safe under Australian outback conditions where heat, dust, and vibration are part of daily life.
Purpose-built for caravan, motorhome, camper trailer, and 4WD canopy electrical systems, this isolator mounts securely on a standard 35mm DIN rail inside any distribution board or enclosure and gives you a clear manual ON/OFF toggle for controlled shutdowns during servicing or system expansion. Whether you're wiring up an off-grid bush camp solar setup, protecting a lithium battery bank in your RV, or safeguarding DC loads in a campervan conversion, the Slocable 2P MCB provides the IEC 60947-2-compliant protection trusted by Australian solar and automotive electricians.
Key Features
- 500V DC rated, 25A continuous current — compatible with 12V, 24V, and 48V solar and battery systems
- 2-pole (double-pole) design simultaneously disconnects both positive and negative conductors
- 6kA breaking capacity with thermal-magnetic trip for overload and short-circuit protection
- 35mm DIN rail mount for fast, secure installation in enclosures and distribution boards
- IEC 60947-2 compliant with CE and UL certification — built for demanding off-road environments
Delivery, returns & warranty
Shipping & Returns
Shipping
Outdoor Camping Australia operates a nationwide distribution network, with items shipping from:
- Our warehouse in Bendigo, Victoria
- Partner supplier warehouses on the East Coast
- Partner supplier warehouses on the West Coast
This multi-location approach allows us to provide efficient delivery across Australia. Use our shipping calculator on the product pages for accurate delivery times and costs to your location.
Important Shipping Notes:
- We cannot deliver to PO Boxes, Private Mail Bags or Parcel Lockers
- Depot pickup options may be available at reduced rates (contact us to discuss)
- Off-mainland deliveries require additional shipping fees (custom quoted)
- Missed deliveries may incur a redelivery fee set by the courier
- All shipments managed through our trusted delivery partners including Border Express, VicTas, DHL, StarTrack, AusPost, Sendle and Aramex
Returns
As outlined in our Refund Policy, we follow the Australian Consumer Law (ACL) which protects consumers by providing certain guaranteed rights when buying goods and services.
You can return items if:
- The product is faulty or not of merchantable quality
- The product is not fit for its intended purpose
- The product does not match the description
- You can present proof of purchase
For change of mind returns:
- Item must be in original condition with tags attached
- Must be returned within 30 days of purchase
- Original proof of purchase required
- Return shipping is at customer's expense
- Original delivery charges are non-refundable unless due to our error
Refunds will be processed within 10 business days of receiving and inspecting the return.
For full details, please refer to our:
Warranty Details
+
Warranty Details
+
- 12-month manufacturer warranty against defects in materials and workmanship.
Specifications
| Brand | Slocable |
|---|---|
| Model / SKU | MCB500252P |
| Rated Voltage | 500V DC |
| Rated Current | 25A |
| Number of Poles | 2P (Double Pole) |
| Breaking Capacity | 6kA (Icu/Ics) |
| Trip Mechanism | Thermal-Magnetic |
| Trip Curve | C Curve |
| Mounting Type | 35mm DIN Rail |
| Application | DC Solar PV systems, battery banks, combiner boxes |
| Housing Material | Flame-retardant thermoplastic |
| Operating Temperature | -25°C to +70°C |
| Compliance | IEC 60947-2, CE, UL Listed |
| Compatible Voltage Systems | 12V, 24V, 48V DC solar and battery systems |
| Suitable For | Caravans, motorhomes, campervans, 4WD campers, marine, off-grid cabins |
