12V 200AH Lithium Rechargeable Battery by Sphere

12V 200AH Lithium Rechargeable Battery by Sphere Sphere

12V 200AH Lithium Rechargeable Battery

Name: 12V 200AH Lithium Rechargeable Battery by Sphere
Brand: Sphere
SKU: 500-00834
Price: 1699.0 AUD
Availability: InStock

SKU 500-00834

$2,231.00

$1,699.00

Save $532.00

Capacity: 200AH
Operating Temperature: 0°C to 45°C

All specifications

or pay now with

Questions? for expert advice, or read our buying guides

Key features

200AH lithium ion capacity with high usable energy output
2,000+ charge/discharge cycles at 80% depth of discharge
Built-in advanced BMS with dynamic cell balancing for cell protection and longevity
Significantly lighter than equivalent AGM or lead-acid batteries
Supports series and parallel connection — maximum in-series voltage of 30.4V
Suitable for caravan, motorhome, marine, RV, camper trailer, and off-grid solar applications
Deep discharge recovery capability with stable voltage output under load
3-year manufacturer warranty for peace of mind on the road
Low self-discharge rate ideal for seasonal or intermittent use
Not suitable for starting motor vehicles — deep-cycle use only

Overview

The Sphere 12V 200AH Lithium Rechargeable Battery delivers serious deep-cycle power in a package that weighs a fraction of equivalent AGM or lead-acid batteries. Built on proven lithium ion cell chemistry with a built-in advanced Battery Management System (BMS) featuring dynamic cell balancing, this battery consistently delivers its full rated 200AH of usable capacity — no more counting on only 50% of a lead-acid bank. With 2,000+ charge cycles at 80% depth of discharge, it offers a service life many times greater than traditional batteries, making it one of the most cost-effective long-term power storage solutions available for Australian 12V systems.

Purpose-built for caravans, camper trailers, motorhomes, and off-grid 4WD setups across Australia, this Sphere lithium battery thrives in the demanding conditions of outback touring and extended off-road travel. Its lighter weight means less load on your van or vehicle, while the flexible series/parallel connection capability (up to 30.4V in series) lets you scale your battery bank as your power needs grow. Whether you're running a fridge, lighting, an inverter, or a full RV solar system, the Sphere 200AH lithium battery is a reliable, high-performance foundation for any 12V camping or caravanning power setup. Not suitable for engine starting.

Key Features

200AH usable lithium capacity — far more effective than equivalent-rated AGM or lead-acid batteries
Built-in advanced BMS with dynamic cell balancing for protection and longevity
2,000+ charge cycles at 80% DoD for exceptional long-term value
Lightweight design — significantly lighter than AGM or lead-acid alternatives
Flexible series/parallel connection — scale up to 30.4V max in series for larger battery banks

Specifications

Dimensions: 365x185x245mm
Chemical: Lithium Iron LiFePo4
Product Weight: 19.7kg
Operating Temperature Range: -20°C ~ +60°C
Voltage: 12.8VDC
Amperage: 200AH
Max Continuous Current: 100A
Max 10 Second Pulse: 150A
Min Charge Current: 2A
Nominal Charge Rate: 30A
Max Charge Current: 100A
Max Charge Voltage: 14.8V
Recommended Charge Rate: 30A
Cell Balancing: 5A H charge & discharge
Cycles @ 100% DOD: DOD 2000 Cycles
Cycles @ 80% DOD: DOD 3000 Cycles
Cycles @ 50% DOD: DOD 3500 Cycles
Cycles @ 30% DOD: DOD 8000 Cycles
Low Voltage cut out: 10.0VDC
Maximum In-series voltage: 30.4V
